ZHX-ML616D 4-SIDED PLANNER (WITH SAW SHAFT) | MCB THUONG NGUYEN WOOD

✨ FOUR-SIDED PLANER WITH SAW SPINDLE – 100% NEW

✅ BRAND: ZHONGHAO XING
🌏 ORIGIN: CHINA
🔧 MODEL: ZHX-ML616D
📦 CONDITION: BRAND NEW – IN STOCK

🛠 DETAILED SPECIFICATIONS:

• Max working width: 20 – 200 mm

• Max working thickness: 10 – 160 mm

• Min working length: 480 – 650 mm

• Air pressure requirement: 0.3 – 0.6 Mpa

⚙️ SPINDLE & CUTTER SYSTEM:

• Cutter spindle diameter: Ø40 mm – Speed: 6000 RPM

• Saw spindle diameter: Ø40 mm – Speed: 4500 RPM

• Saw spindle keyway: 12 x 4 mm

• 1st bottom cutter diameter: Ø125 mm

• Left/Right vertical cutter diameter: Ø110 ~ 180 mm

• Left/Right saw blade diameter: Ø180 ~ 250 mm

🔩 POWERFUL MOTORS – STABLE PERFORMANCE:

• 1st bottom spindle motor: 4 kW

• Left & right vertical cutter motor: 2 x 15 kW

• Left & right saw spindle motor: 2 x 1.5 kW

• Main feed motor: 3 kW

• Rear auxiliary feed motors: 2 x 0.37 kW

• Lifting motor: 0.75 kW

• Total power consumption: 46.49 kW

🚀 HIGH EFFICIENCY – FEED SPEED:

• Feed speed: 5 – 35 m/min

• Feed wheel diameter: Ø140 mm

• Dust outlet size: 2 x Ø150 mm + 4 x Ø120 mm

📏 DIMENSIONS & WEIGHT:

• Machine dimensions (LxWxH): 3830 x 1400 x 1800 mm

• Net weight: 2600 kg

✅ KEY ADVANTAGES:

• Equipped with dual saw spindles – boosts productivity & versatility

• Robust structure ensures smooth operation and precise cutting

• Suitable for solid wood, industrial wood, laminated boards

• Standard dust extraction system – ensures cleanliness and safety

• Designed for 24/7 factory operation
