BOX SANDER – M3T–CLF | MCB THUONG NGUYEN WOOD

🎯 OUTSTANDING FEATURES:

✅ Unique sanding technology – The sanding key system automatically adjusts to the product surface.
✅ Flexible, soft yet extremely effective – Preserves the wood grain while ensuring maximum smoothness.
✅ Optimize production time – Fast, even scrubbing, saving labor.
✅ Superior quality – High standard finished products, ready for export.
✅ Veneer processing in horizontal and vertical directions.
✅ Sanding different types of wood and paint.
✅ Accurate and precise solid wood leveling and polishing.
✅ Suitable for different shapes such as:
✅ Rectangular, round, oval, and asymmetrical patterns.
✅ The maximum working width is 1300mm and the shortest workpiece that can be made is 250mm thanks to the vacuum suction unit built into the machine.
✅ The machine integrates 82 sensors that detect asymmetrical positions on the wood surface, thereby transmitting working commands to the next parts. Each PIANO key controls 2 sensors during the sanding process.
✅ In particular, the machine is equipped with a motor that saves 4 times more electricity and does not reduce force when operating the machine.
✅ The control computer has Ethernet so that technicians can analyze faults remotely, and has a zone control function.
✅ The safety shut-off feature automatically stops the machine when there is a problem during operation or incorrect operation (opening the door while the machine is operating).
✅ Electromagnetic driving technology ensures pressure precision when processing objects with intricate shapes, thin veneers and painted surfaces.
✅ A machine that can integrate many functions and handle like an intelligent robot is the optimal choice for modern furniture factories that require high quality.

🧵 BASIC SPECIFICATIONS

– Model M3T

* ChiaLung Brand – Taiwan

– Working width: 1350 mm

– Working height: 4-80 mm

– Piano spindle motor: 15 Hp

– A-type sanding shaft motor with lead sandpaper: 15 Hp

– 2-band A-type scrubbing shaft motor: 15 Hp

– Board cleaning brush shaft motor: 0.5hp

– Vacuum conveyor system

– Screen control system: 12 inches
